 SATA Cable / SAS Internal Cable


 For additional information on each product, contact PDE Technology today.




INT SAS/SATA Fan Out Cable, 8484 - 4X 8482 with Power

Internal SAS / SATA Cable Fan Out 29-1468: 1M

INT SATA Signal Cable

SATA Cable Signal  29-0510: 12"
     -0454: .5M
     -0455: 1M
     -0504: 1.5M
     -0456: 2M
     -0505: 2.5M
     -0506: 3M

     -0507: 4M
     -0508: 5M
INT SATA Cable Straight To R

SATA Cable Straight to R 29-0487: .5M

EXT SATA1-SATA2

 29-1143: 1M
    -1144: 2M


EXT SATA2-SATA2

 29-1145: 1M
    -1146: 2M

INT SATA Cable M-F

Internal SATA Cable 29-1148: 6"

INT SATA DR-SATA/POWER Cbl

SATA Power Cable 29-1147-R: 6"
    -1147-16-R: 16"


INT SATA DR-SATA2F/PWR Cable

Internal SATA Cable with Power 29-1147-16: 16"

Power Y Serial ATA

 29-0457-Y: 6"

Power Serial ATA, ATA-4P

 29-0457: 6"

Power Cbl, ATA-4P Adapter
Internal SATA Cable PNL Mount

  29-0464: .5M
     -0464-01: 1M
     -0464-05: 5"
     -0464-10: 10"

SAS Drive Cable 6"

  29-1425: 6"

29 Pin SAS drive connector (SFF-8482) to 7 pin Serial ATA connector & 4 pin DC power cable connector
SAS Drive Cable 18"

  29-1425-18: 18"

29 Pin SAS drive connector (SFF-8482) to 7 pin Serial ATA connector & 4 pin DC power cable connector
SATA2 to Single Int. SATA Adapter

  23-1072

Includes C50 size cut out bracket. Used on an external storage enclosure to bring an internal Serial ATA connection from a drive to a single eSATA bulkhead external connection.
SATA/SAS 4X Multilane to 4 Int. SATA Adapter

  23-1075

Includes C50 size cut out bracket. Used on an external storage enclosure to bring 4 internal Serial ATA connections from 4 drives to a single 4X multilane bulkhead external connection.
Mini-SAS 8088 Adapters
SAS I/O Adapter

 14-1660

 14-1660-CO: (8088 Cross Over Pin Out)



Input and Output adapter to 4 internal SAS bus connections with 8088 external connector. Attached to a metal C50 Plate.
Mini-SAS 8088 Adapters
SAS Dual I/O Adapter

 14-1661

 14-1661-CO: (8088 Cross Over Pin Out)



Input and Output adapter to 8 internal SAS bus connections with two 8088 external connectors. Attached to a metal C50 Plate.
Mini-SAS 8088 Adapters
SAS PCI Adapter

 14-1662-CO (8088 Cross Over Pin Out)


Input and Output adapter to 4 internal SAS bus connections with 8088 external cross over pin out. Attached to a PCI bracket.
Mini-SAS 8088 Adapters
SAS Mini PCI Adapter

 14-1663-CO (8088 Cross Over Pin Out)


Input and Output adapter to 4 internal SAS bus connections with 8088 external cross over pin out. Attached to a Mini PCI bracket.
Mini-SAS 8088 Adapters
SAS PCI Dual Adapter

 14-1664-CO (8088 Cross Over Pin Out)


Input and Output adapter to 8 internal SAS bus connections with two 8088 external cross over pin out. Attached to a PCI bracket.
Mini-SAS 8088 Adapters
SAS I/O Adapter


 14-1665

Input and Output adapter to 2 internal SAS bus connections with 8088 external connector. Attached to a metal C50 Plate.
Power Adapter for Serial ATA

  14-1628

4 pin female power connector – 15 pin male SATA power connector. Can be used with E100, E300, E400 to allow the power connection to a server power supply connector.
2.5" HDD Mounting Kit for SATA Notebook HDD

  14-1612

Converts the form factor of any 2.5" hard drive to a 3.5" form factor and Converts the drive connector to a standard SATA data connector and 4 pin power connector. Kit includes bracket, hardware, and adapter cable.
Serial ATA Adapter

  14-1618

7 pin Male – 7 pin Male, Serial ATA Coupler. Connects 2 Internal SATA cables together.






See Additional Related Links: Mini-SAS Cables | SAS Cables
