Mini-SAS Cable - SAS Cable - Adapters


For additional information on each product, contact PDE Technology today.



Mini-SAS Cable 8087 - 8087
Mini-SAS Cable for 8087-8087
29-1352: Internal 36 - 36 pin, Mini-SAS Cable assembly  .5 METER
    -1353:
Internal 36 - 36 pin, Mini-SAS Cable assembly  1 METER

Internal Mini-SAS Cable 8087 - 8484
Internal Mini-SAS Cable for 8087-8484
29-1314: Internal 8087 36 - SFF8484 32 pin, Mini-SAS Cable assembly  .5 METER
Mini-SAS 8087 - 4 Individual SATA Cable
4 SATA to MiniSAS 8087 Cable 29-1320: Internal 36 - 4 individual SATA connectors, Mini-SAS Cable assembly  1 METER

SAS Internal 8484 - 4 individual SATA Cable
SAS Cable to SATA Cables 29-1284: Internal 32 pin 8484 - 4 individual SATA connectors, Cbl assembly  .5 METER
    -1284-650:
Internal 32 pin 8484 - 4 individual SATA connectors, Cbl assembly  650 mm
    -1321: Internal 32 pin 8484 - 4 individual SATA connectors, Cbl assembly  2 METER
Mini-SAS 8087 - 8484 Reverse Straight (For Backplane)
Mini-SAS Cables for 8087 to 8484
29-1289: Internal 36 - 36 pin SFF 8484 32 pin Reverse straight pin out, Cbl assembly  22"
External 8088 26 pin - 8088 26 pin
Mini-SAS 8088 to 8088 Cable
29-1366: .5 METER
    -1290: 1 METER
    -1291: 2 METER
    -1293: 3 METER
    -1294: 5 METER

External 8088 26 pin - External 4X Univ. 8470 Multilane
Mini-SAS 8088 to 8470 Cable
29-1295: 1 METER
    -1296: 2 METER
    -1297: 3 METER
    -1298: 5 METER

External PCIe x8 CABLE
29-1538: External PCIe x8 Cable  1 METER
    -1539: External PCIe x8 Cable  2 METER


Internal 8088 - 8087
29-1516: .5 METER
    -1518: 1 METER

Internal SAS 8470 - 8087, Multilane 4X
29-1517: Multilane 4X - Mini-SAS Internal, .5 METER
    -1519: Multilane 4X - Mini-SAS Internal, 1 METER

SFF 8087 to 4x 8482 with Power
29-1498: SFF 8087 to 4x 8482 with Power, 1 METER


Multilane 8470 - 4 Individual SATA Connectors
29-1322: SFF8470 Multilane - 4 Individual SATA connectors  2 METER

Adapters
14-1660 SAS I/O Adapter


14-1660-CO (8088 Cross Over Pin Out) SAS I/O Adapter


Input and Output adapter to 4 internal SAS bus connections with 8088 external connector. Attached to a metal C50 Plate.


14-1661 SAS Dual I/O Adapter


14-1661-CO (8088 Cross Over Pin Out) SAS Dual I/O Adapter


Input and Output adapter to 8 internal SAS bus connections with two 8088 external connectors. Attached to a metal C50 Plate.


14-1662-CO (8088 Cross Over Pin Out) SAS PCI Adapter

Input and Output adapter to 4 internal SAS bus connections with 8088 external crossover pin out. Attached to a PCI bracket.



14-1663-CO (8088 Cross Over Pin Out) SAS Mini PCI Adapter

Input and Output adapter to 4 internal SAS bus connections with 8088 external crossover pin out. Attached to a Mini PCI bracket.



14-1664-CO (8088 Cross Over Pin Out) SAS PCI Dual Adapter

Input and Output adapter to 8 internal SAS bus connections with two 8088 external crossover pin out. Attached to a PCI bracket.



14-1665 SAS I/O Adapter

Input and Output adapter to 2 internal SAS bus connections with 8088 external connector. Attached to a metal C50 Plate.



14-1700 SAS I/O Adapter

8088 - 8087 with C50 Plate
14-1700-CO SAS I/O Adapter with Crossover

8088 - 8087, Crossover with C50 Plate

14-1701 SAS Dual I/O Adapter

8088 - 8087 with C50 Plate
14-1701-CO SAS Dual I/O Adapter with Crossover

8088 - 8087, Crossover with C50 Plate

14-1702 SAS I/O Adapter

8088 - 8087 with PCI Plate
14-1702-CO SAS I/O Adapter with Crossover

8088 - 8087, Crossover with PCI Plate

14-1703 SAS Dual I/O Adapter

8088 - 8087 with PCI Plate
14-1703-CO SAS Dual I/O Adapter Crossover

8088 - 8087, Crossover with PCI Plate

14-1704 SAS I/O Adapter

8088 - 8087 with Mini PCI Plate
14-1704-CO SAS I/O Adapter with Crossover

8088 - 8087, Crossover with Mini PCI Plate

14-1740 SAS I/O Adapter

8644-8087 with C50 Cut Out Bracket
(4x HD Mini-SAS SFF-8644 external 36 pin - 4x Mini-SAS internal 36 pin SFF-8087)
14-1740-CO SAS I/O Adapter with Crossover

8644-8087 Crossover pin out with C50 Cut Out Bracket
(4x HD Mini-SAS SFF-8644 external 36 pin - 4x Mini-SAS internal 36 pin SFF-8087)
Crossover
