Bridge Boards


For additional information on each product, contact PDE Technology today.

PDE Part #:  14-1601
Bridge Boards: SATA or PATA (IDE)


Bridge boards for USB to SATABridge boards that connect a USB host to a SATA or ATA hard disk drive in an enclosure. The Bridge Board is mounted on a standard C50 cutout bracket to mount in an enclosure C50 cable cutout. Supports a single SATA hard drive, a single ATA hard drive, or 2 ATA hard drives, configured as master slave.

CONTENTS:
Bridge Boards, Power Cable, Sata Cable, ATA cable, Cutout bracket.
PDE Part #:  14-1602
Bridge Boards: SATA

USB or Firewire bridge to SATA Hard Drive through boardsBridge boards that connect a USB host or a firewire 1394 host to a SATA hard disk drive in an enclosure. The Bridge Board is mounted on a standard C50 cutout bracket to mount in an enclosure C50 cable cutout. Supports 1 or 2 SATA hard drives, the board can be jumpered as a JBOD (2 individual drives) or as striped mode where 2 hard drives can be striped for faster performance. The host connection is USB B type or Firewire B type.

CONTENTS:
Bridge Boards, Power Cable, Sata Cable, Cutout Bracket.
